SMART SLIDING GATES

HomeSmart homeSmart GatesSMART SLIDING GATES

Make your gate SMART with our SMART CONTROL UNIT!

Clean and elegant design, quick and easy installation.

TECHNICAL DATADETAILS
ConnectivityBluetooth
Power supply230Vac 50-60Hz
Flashing light output230Vac 100W max.
Motor output230Vac 50/60Hz 750W max.
Power supply to photocells24Vac 3W max
Working temperature-10/+55 °C
Radio receiver (integrated)433Mhz
TX max codes in memory100 (CODE or PED CODE)
Board dimensions105x95x64mm
Selectable logic:Automatic or step-by-step
Slow down and soft start adjustable functions
Pedestrian openingwith pedestrian working time adjustment
1 safety device input
Easy electronic power adjustment
External devices connectionNormally open free contact
Limit Switches InputsNC Free Contacts
